Posted On January 16, 2025
This large Midwest beef processing plant needed to maintain precise temperature control at a point-of-use hot water station for beef feet cleaning (a CCP – critical control point). As the final product is for human consumption, beef feet cleaning must reach and maintain proper temperature per USDA requirements. If 160°F [71°C] is not met, this will result in a loss of product, time, and energy.
Flow Rate:
0-75 GPM [0-17 m³/hr]
Inlet Temperature:
140°F [60°C]
Discharge Temperature:
160°F [71°C]
Water Pressure:
50 PSIG [3.4 barg]
Steam Supply Pressure:
120 PSIG [8.3 barg]
SOLUTION
Hydro-Thermal® replaced (3) Emech mixing valves with an H2015 EZ Skid™ system dedicated to the beef feet point-of-use station. By adding this system, the plant was able to lower its central hot water system set-point from 160°F [71°C] to 140°F [60°C].
By replacing their valves with the EZ Skid™, the processing plant saved on energy, time, maintenance and ensured product quality with an estimated $42,000/yr in energy savings.
GOAL
• Maintain precise temperature control
• Decrease batch time
• Enhance product quality
ACCOMPLISHMENTS
• Lowered set-point temperature
• 6 month ROI
• Simplified the point-of-use process
• Reduced maintenance to a once a year check
